Convert xgb.Booster model to party object — as.party.xgb.Booster • lorax

Convert a single tree from an xgboost boosted tree model to a party object for use with partykit visualization and analysis tools.

Usage

# S3 method for class 'xgb.Booster'
as.party(obj, tree = 1L, data, ...)

Arguments

obj: An xgb.Booster object from the xgboost package.
tree: Integer specifying which tree to convert (1-based indexing, default is 1). For multiclass models with num_class classes and nrounds boosting rounds, there are num_class * nrounds total trees.
data: data.frame containing the training data with the response variable included (required). XGBoost models do not store the original training data or response values. You must provide the original data frame that includes both the predictor variables and the response variable.
...: Not currently used.

Value

A constparty object from the partykit package.

Details

Important note on data

XGBoost models do not store the original training data or response values. You must provide the original data frame (including the response variable) via the data parameter for correct terminal node statistics, bar charts, and other visualizations.

XGBoost tree storage format

xgboost stores trees in a tabular format accessible via xgboost::xgb.model.dt.tree(). Each tree is represented as rows in a table:

Tree: 0-based tree index (e.g., 0, 1, 2, ...)
Node: 0-based node ID within tree (e.g., "0-0", "0-1" for tree 0)
Feature: Feature name (character) or "Leaf" for terminal nodes
Split: Numeric threshold for splits (NA for leaves)
Yes: 0-based node ID of yes branch (feature < threshold)
No: 0-based node ID of no branch (feature >= threshold)
Missing: 0-based node ID for missing values
Quality: Prediction value for leaf nodes, gain for internal nodes

Node indexing

Internally, xgboost uses 0-based tree and node indices
User-facing tree parameter uses 1-based indexing (R convention)
When tree=1 is requested, we filter to Tree==0 internally

Split encoding

Yes branch: feature < threshold (left child)
No branch: feature >= threshold (right child)
partykit split created with right = TRUE (right interval closed)

Child node references

Yes column: node ID for left child (< condition)
No column: node ID for right child (>= condition)
Leaf nodes have Feature == "Leaf"

Variable names

Feature column contains actual feature names (not indices)
Must map to column positions in data.frame
If numeric indices used (f0, f1, ...), map to data columns

The party object will use 1-based node IDs and variable indices as required by partykit.

Examples

if (rlang::is_installed("xgboost")) {
  data(agaricus.train, package = "xgboost")

  # Binary classification example
  train_data <- as.data.frame(as.matrix(agaricus.train$data))
  train_data$label <- agaricus.train$label

  dtrain <- xgboost::xgb.DMatrix(agaricus.train$data, label = agaricus.train$label)

  set.seed(3691)
  bst <- xgboost::xgb.train(
    data = dtrain,
    max_depth = 3,
    nrounds = 3,
    objective = "binary:logistic",
    verbose = 0
  )

  # Convert first tree - data parameter is required
  party_tree <- as.party(bst, tree = 1L, data = train_data)
  print(party_tree)
  plot(party_tree)

  # Regression example
  data(mtcars)
  reg_data <- mtcars
  dtrain_reg <- xgboost::xgb.DMatrix(as.matrix(mtcars[, -1]), label = mtcars$mpg)

  set.seed(9158)
  bst_reg <- xgboost::xgb.train(
    data = dtrain_reg,
    max_depth = 3,
    nrounds = 3,
    objective = "reg:squarederror",
    verbose = 0
  )

  party_tree_reg <- as.party(bst_reg, tree = 1L, data = reg_data)
  print(party_tree_reg)
}
#> Warning: Passed invalid function arguments: max_depth. These should be passed as a list to argument 'params'. Conversion from argument to 'params' entry will be done automatically, but this behavior will become an error in a future version.
#> Warning: Argument 'objective' is only for custom objectives. For built-in objectives, pass the objective under 'params'. This warning will become an error in a future version.
#>
#> Model formula:
#> ~`odor=none` + `spore-print-color=green` + `stalk-root=club` +
#>     `stalk-surface-below-ring=scaly` + `bruises?=bruises` + `stalk-root=rooted` +
#>     `odor=foul`
#>
#> Fitted party:
#> [1] root
#> |   [2] odor=none <= 2.00001
#> |   |   [3] spore-print-color=green <= 2.00001: 0.057 (n = 6513, err = 348.1)
#> |   |   [4] spore-print-color=green > 2.00001
#> |   |   |   [5] stalk-surface-below-ring=scaly <= 2.00001: NA (n = 0, err = NA)
#> |   |   |   [6] stalk-surface-below-ring=scaly > 2.00001: NA (n = 0, err = NA)
#> |   [7] odor=none > 2.00001
#> |   |   [8] stalk-root=club <= 2.00001
#> |   |   |   [9] bruises?=bruises <= 2.00001: NA (n = 0, err = NA)
#> |   |   |   [10] bruises?=bruises > 2.00001: NA (n = 0, err = NA)
#> |   |   [11] stalk-root=club > 2.00001
#> |   |   |   [12] stalk-root=rooted <= 2.00001: NA (n = 0, err = NA)
#> |   |   |   [13] stalk-root=rooted > 2.00001: NA (n = 0, err = NA)
#>
#> Number of inner nodes:    6
#> Number of terminal nodes: 7

#> Warning: Passed invalid function arguments: max_depth. These should be passed as a list to argument 'params'. Conversion from argument to 'params' entry will be done automatically, but this behavior will become an error in a future version.
#> Warning: Argument 'objective' is only for custom objectives. For built-in objectives, pass the objective under 'params'. This warning will become an error in a future version.
#>
#> Model formula:
#> ~cyl + wt + hp + disp
#>
#> Fitted party:
#> [1] root
#> |   [2] cyl <= 6
#> |   |   [3] wt <= 2.32: 30.067 (n = 6, err = 44.6)
#> |   |   [4] wt > 2.32
#> |   |   |   [5] hp <= 97: 23.333 (n = 3, err = 1.7)
#> |   |   |   [6] hp > 97: 21.450 (n = 2, err = 0.0)
#> |   [7] cyl > 6
#> |   |   [8] cyl <= 8
#> |   |   |   [9] wt <= 3.435: 20.775 (n = 4, err = 1.6)
#> |   |   |   [10] wt > 3.435: 18.367 (n = 3, err = 1.1)
#> |   |   [11] cyl > 8
#> |   |   |   [12] hp <= 205: 16.786 (n = 7, err = 16.6)
#> |   |   |   [13] hp > 205: 13.414 (n = 7, err = 28.8)
#>
#> Number of inner nodes:    6
#> Number of terminal nodes: 7
