Convert lgb.Booster model to party object — as.party.lgb.Booster • lorax

Convert a single tree from a lightgbm boosted tree model to a party object for use with partykit visualization and analysis tools.

Usage

# S3 method for class 'lgb.Booster'
as.party(obj, tree = 1L, data, ...)

Arguments

obj: An lgb.Booster object from the lightgbm package.
tree: Integer specifying which tree to convert (1-based indexing, default is 1). For multiclass models with num_class classes and nrounds boosting rounds, there are num_class * nrounds total trees.
data: data.frame containing the training data with the response variable included (required). LightGBM models do not store the original training data or response values. You must provide the original data frame that includes both the predictor variables and the response variable.
...: Not currently used.

Value

A constparty object from the partykit package.

Details

Important note on data

lightgbm models do not store the original training data or response values. You must provide the original data frame (including the response variable) via the data parameter for correct terminal node statistics, bar charts, and other visualizations.

LightGBM tree storage format

lightgbm stores trees in a tabular format accessible via lightgbm::lgb.model.dt.tree(). Each tree is represented as rows in a table:

tree_index: 0-based tree index
split_index: 0-based node ID for internal nodes (NA for leaves)
leaf_index: 0-based node ID for leaf nodes (NA for internal)
split_feature: Feature name (character) for splits
threshold: Numeric threshold for splits
decision_type: Split type ("<=", "==", etc.)
left_child: 0-based node ID of left child
right_child: 0-based node ID of right child
leaf_value: Prediction value for leaf nodes
node_parent: 0-based parent node ID
depth: Depth of node in tree

Node indexing

Internally, lightgbm uses 0-based tree and node indices
User-facing tree parameter uses 1-based indexing (R convention)
When tree=1 is requested, we filter to tree_index==0 internally
Internal nodes use split_index, leaf nodes use leaf_index

Split encoding

decision_type "<=": left child when feature <= threshold
right child when feature > threshold
partykit split created with right = FALSE (left interval closed)

Child node references

Internal nodes have explicit left_child and right_child IDs
These reference either split_index (internal) or leaf_index (leaf)
Need to look up child in appropriate column based on node type

Variable names

split_feature column contains actual feature names or "Column_N" defaults
Must map to column positions in data.frame

The party object will use 1-based node IDs and variable indices as required by partykit.

Examples

if (rlang::is_installed("lightgbm")) {
  # Binary classification example
  data(agaricus.train, package = "lightgbm")

  # Prepare data with response column
  train_data <- as.data.frame(as.matrix(agaricus.train$data))
  train_data$label <- agaricus.train$label

  dtrain <- lightgbm::lgb.Dataset(
    agaricus.train$data,
    label = agaricus.train$label
  )

  set.seed(7264)
  bst <- lightgbm::lgb.train(
    params = list(objective = "binary", max_depth = 3),
    data = dtrain,
    nrounds = 3,
    verbose = -1
  )

  # Convert first tree - data parameter is required
  party_tree <- as.party(bst, tree = 1L, data = train_data)
  print(party_tree)
  plot(party_tree)

  # Regression example
  data(mtcars)
  reg_data <- mtcars
  dtrain_reg <- lightgbm::lgb.Dataset(as.matrix(mtcars[, -1]), label = mtcars$mpg)

  set.seed(6381)
  bst_reg <- lightgbm::lgb.train(
    params = list(objective = "regression", max_depth = 3, min_data_in_leaf = 1),
    data = dtrain_reg,
    nrounds = 3,
    verbose = -1
  )

  party_tree_reg <- as.party(bst_reg, tree = 1L, data = reg_data)
  print(party_tree_reg)
}
#>
#> Model formula:
#> ~`odor=none` + `stalk-root=club` + `stalk-root=rooted` + `bruises?=bruises` +
#>     `spore-print-color=green` + `stalk-surface-below-ring=scaly` +
#>     `odor=musty` + `odor=foul`
#>
#> Fitted party:
#> [1] root
#> |   [2] odor=none < 0
#> |   |   [3] stalk-root=club < 0
#> |   |   |   [4] stalk-root=rooted < 0: 0.000 (n = 3090, err = 0.0)
#> |   |   |   [5] stalk-root=rooted >= 0: 0.000 (n = 158, err = 0.0)
#> |   |   [6] stalk-root=club >= 0
#> |   |   |   [7] bruises?=bruises < 0: 0.000 (n = 32, err = 0.0)
#> |   |   |   [8] bruises?=bruises >= 0: 0.510 (n = 418, err = 104.5)
#> |   [9] odor=none >= 0
#> |   |   [10] spore-print-color=green < 0
#> |   |   |   [11] stalk-surface-below-ring=scaly < 0: 0.043 (n = 2719, err = 111.1)
#> |   |   |   [12] stalk-surface-below-ring=scaly >= 0: 0.302 (n = 43, err = 9.1)
#> |   |   [13] spore-print-color=green >= 0: 0.509 (n = 53, err = 13.2)
#>
#> Number of inner nodes:    6
#> Number of terminal nodes: 7

#>
#> Model formula:
#> ~wt + qsec + hp + cyl
#>
#> Fitted party:
#> [1] root
#> |   [2] wt < 2.26
#> |   |   [3] qsec < 19.17
#> |   |   |   [4] wt < 1.885: 30.400 (n = 2, err = 0.0)
#> |   |   |   [5] wt >= 1.885: 26.650 (n = 2, err = 0.8)
#> |   |   [6] qsec >= 19.17
#> |   |   |   [7] hp < 65.5: 33.900 (n = 1, err = 0.0)
#> |   |   |   [8] hp >= 65.5: 32.400 (n = 1, err = 0.0)
#> |   [9] wt >= 2.26
#> |   |   [10] cyl < 7
#> |   |   |   [11] cyl < 5: 22.580 (n = 5, err = 6.0)
#> |   |   |   [12] cyl >= 5: 19.743 (n = 7, err = 12.7)
#> |   |   [13] cyl >= 7
#> |   |   |   [14] hp < 192.5: 16.786 (n = 7, err = 16.6)
#> |   |   |   [15] hp >= 192.5: 13.414 (n = 7, err = 28.8)
#>
#> Number of inner nodes:    7
#> Number of terminal nodes: 8
